Description
It offers a capacity of 2000 VA / 1200 W and operates with a nominal input voltage of 220/230/240 VAC, with an operating voltage range of 162–290 VAC and automatic frequency sensing at 50/60 Hz. The unit delivers an output voltage with ±10% regulation in battery mode and a frequency range of 50/60 Hz ±1, featuring a fast transfer time of typically 2–6 ms (maximum 10 ms). It produces a simulated sine wave output and utilizes a 24 V battery system (2 × 12V batteries, 9 Ah each) with a typical recharge time of 6–8 hours to reach 90% capacity. Equipped with microprocessor-based control, boost and buck AVR stabilization, and cold start capability, it ensures stable operation and improved battery performance. The UPS includes LED indicators with optional LCD display, USB or RS232 communication interface for real-time monitoring, and comprehensive protection features such as short circuit, overload, overcharge, and over-discharge protection. Designed for practical and continuous use, it operates within 0–40°C and up to 90% non-condensing humidity, with noise level below 55 dB. Physically, the unit has dimensions of approximately 380 × 158 × 198 mm and a weight of around 10.5 kg, making it a robust and efficient solution for medium-capacity backup power applications.
Baterai Built In
