Description
It operates with a nominal input voltage of 110/120 VAC or 220/230/240 VAC, with a wide operating voltage range of 81–145 VAC or 162–290 VAC, and frequency range of 50/60 Hz (±10%). The output delivers a simulated sine wave at nominal voltage ±10% in battery mode, with frequency regulation of 50/60 Hz ±1 Hz and a fast transfer time of typically 2–6 ms (maximum 10 ms) to ensure minimal disruption during power outages. The unit is equipped with a 12V / 7Ah battery (1 unit) with a typical recharge time of 6–8 hours to reach 90% capacity. It features full protection against overload and overcharge, along with LED or optional LCD display indicating AC mode, battery mode, load level, and battery status. Additional features include AVR boost and buck stabilization, cold start function, auto restart, built-in self-diagnostics, modem/LAN protection, and optional USB/RS232 communication for power management. Designed for quiet operation (<40 dB), it operates within 0–40°C and up to 95% non-condensing humidity, with a compact form factor of approximately 149.3 × 338 × 162 mm and weight of around 4.25 kg, making it ideal for PCs, networking devices, and small IT equipment. Termasuk Baterai, Boks Baterai dan Jumper | Tanpa Kabel In/Out | Tanpa Panel In Out | Tanpa Kabel BC
